Design Improvements

Single vs Twin Ring Thrust Flinger

Improved Twin Ring Design – All Melett KP35/39 CHRA’s are upgraded from single to twin ring comp end for improved sealing.

Read More…

Thrust Bearing 180° vs 360°

At The original BV35, BV39, KP31, KP35 & KP39 thrust bearing was the 3 pad, 180 degree design. Due to the open thrust pad area oil retention was an issue.

Read More…

GT15-25 Thrust Bearing Design

In the beginning, there were two main types of GT15-25 turbo, those with a sintered steel 270° and those with a 360° stamped brass alloy thrust bearing.

Read More…

Difference Between Stamped Strip and Hot Forged

At Melett, we understand the different methods used to produce thrust bearings and where possible incorporate design improvements.

Read More…

GT15 Journal Bearing Evolution

The GT15 journal bearings have improved over the years. They started with Melett part numbers 1102-015-100 and 1102-015-101.

Read More…

GT15 Seal Plate

Seal plates are prone to failing around the compressor wheel diameter, to improve the strength the Melett  seal plate has been designed to incorporate extra strengthening ribs.

Read More…

GT15 Nozzle Assembly Design

Solid Vane Design – During the design review of the GT15 nozzle assembly, Melett Engineers analysed failure modes of many units.

Read More…
